Heat Shrinkable Tube
Features:
Designed for LV applications
Good electrical & mechanical performance
UV resistance
Operating temperature: -55℃ to 125℃
Fully recovery temperature: 120℃
Technical Data:
Property
Testing Method
Typical Data
Tensile strength
ASTM D 2671
≥14Mpa
Ultimate elongation
ASTM D 2671
≥400%
Volume resistance
IEC 93
1.0×1013. ‘CM
Dielectric strength
IEC 243
18KV/mm
Water absorption
ISO 62/23℃,14 days
＜0.15%
Copper stability
ASTM D 2671
Pass
Density
ASTM D 792
1.05g/cm3
Adhesive peel strength(PE)
DIN 30672
4 N/cm
Softening point
ASTM E 28
85%
Dimensions:
Size (mm)
As supplied diameter(mm)
After recovered
Standard Length
Diameter (mm)
Wall thickness (mm)
(mm)
12/3
12
3
1.8
1000-1220
16/5
16
5
2.0
1000-1220
22/6
22
6
2.2
1000-1220
28/6
28
6
2.5
1000-1220
33/8
33
8
2.5
1000-1220
40/12
40
12
2.5
1000-1220
55/16
55
16
2.7
1000-1220
65/19
65
19
2.8
1000-1220
75/22
75
22
3.0
1000-1220
85/25
85
25
3.0
1000-1220
95/25
95
25
3.0
1000-1220
115/34
115
34
3.3
1000-1220
140/42
140
42
3.5
1000-1220
160/50
160
50
3.5
1000-1220
180/58
180
58
3.5
1000-1220
