| PET Braided Sleeve |
 |
| Features: |
Light weight and flexible
UV resistance
High tensile strength
Flame retardant
Not affected by most chemicals and solvents
Excellent abrasion and moisture resistant
Operating temperature: -40℃ to 125 ℃ |
|
|
| Application: |
| Designed from flame retardant environment friendly PET yarns. Widely used in wire harnessing in industries,cable protection for automotive, marine industry, home theater wire management, customizing computer case wiring, office wire management and scuba hose protection. |
|
|
| Technical Data: |
| Property |
Test Method |
Typical Value |
| Tensile Strength |
ASTM D 2671 |
100.000 psi |
| Elongation |
ASTM D 2671 |
20% |
| Specific Gravity |
ASTM D 876 |
1 |
| Moisture Absorption |
ISO 62 |
0.08% |
| Melt Temperature |
ASTM D 2117 |
250℃ |
| Max. Operating Temperature |
UL244 |
125℃ |
| Resistance to Fungus |
ISO 846 |
PASS |
|
|
|
| Dimensions: |
| Item code |
Expansion range (mm) |
Size (mm) |
Color |
Number of skeins x ends x single wire diameter(mm) |
Standard Packing |
| MPET-3 |
2.4-6.4 |
3 |
Black / Grey |
40 x 1 x 0.25 |
100m/roll |
| MPET-6 |
3.2-11.1 |
6 |
Black / Grey |
32 x 3 x 0.20 |
100m/roll |
| MPET-8 |
6.4-12.7 |
8 |
Black / Grey |
40 x 3 x 0.20 |
100m/roll |
| MPET-10 |
4.8-15.9 |
10 |
Black / Grey |
48 x 3 x 0.20 |
100m/roll |
| MPET-12 |
6.4-19.1 |
12 |
Black / Grey |
56 x 3 x 0.20 |
50m/roll |
| MPET-16 |
9.5-25.4 |
16 |
Black / Grey |
64 x 3 x 0.20 |
50m/roll |
| MPET-19 |
12.7-31.8 |
19 |
Black / Grey |
72 x 3 x 0.20 |
50m/roll |
| MPET-25 |
15.9-38.1 |
25 |
Black / Grey |
72 x 3 x 0.25 |
25m/roll |
| MPET-32 |
19.1-44.5 |
32 |
Black / Grey |
96 x 3 x 0.25 |
25m/roll |
| MPET-38 |
25.4-63.5 |
38 |
Black / Grey |
96 x 4 x 0.20 |
25m/roll |
| MPET-45 |
31.8-69.9 |
45 |
Black / Grey |
96 x 4 x 0.25 |
25m/roll |
| MPET-51 |
38.1-88.9 |
51 |
Black / Grey |
120 x 5 x 0.20 |
25m/roll |
| MPET-64 |
44.5-114.3 |
64 |
Black / Grey |
120 x 5 x 0.25 |
25m/roll |
| MPET-76 |
63.5-120.7 |
76 |
Black / Grey |
120 x 5 x 0.25 |
25m/roll |
Related information:
The product is supplied as rolls of specified dimensions with spool and cartons. Recommend to store in original packing, protected from moisture, dust, heat and sunlight. |
|
|
